Product Details
- ENERGY STAR® Qualified
- High efficiency operation with up to 0.90 UEF
- Includes Leak Detection smart sensor that alerts audibly and visually if a leak occurs
- Unique side fired Ultra-Low NOx gas burner, meets or exceeds emission requirements in California & Utah
- Power Vent and Power Direct Vent with a single design
- Side-Mounted Hot and Cold Recirculating taps
- Spiral heat exchanger keeps hot combustion gases in the tank longer to lengthen the heat transfer cycle
- Blue Diamond® glass coating provides superior corrosion resistance compared to industry standard glass lining.
- Thermal Efficiency up to 93%
- 8-year Limited Tank and Parts Warranty
Commercial-grade hot water delivery is now more attainable than ever. The Premier® High Value Condensing provides
flexible, powerful and highly efficient performance to the everyday home. The fully condensing
design is so advanced, it can deliver “continuous hot water for shower after shower”at a constant
flow of over 2.5 gallons per minute.*
*Continuous hot water based on 65,000 BTU unit, 2.8 GPM continuous flow with a 65°F inlet water temperature, 110°F outlet temperature, and a unit installed per the manufacturer’s instructions.
Specifications
Tech Specs
Nominal Gallon Capacity
40 Gallons
Rated Storage Volume
39.4 Gallons
UEF
0.9
Maximum BTUs
50,000
Power Source
GAS
Limited Tank Warranty
8 Years
Limited Parts Warranty
8 Years
T&P Relief Valve
Yes
Water Connection Location
TOP
Emissions
Ultra-Low NOx
First Hour Rating
86 Gallons
ASME Certified
No
Amperes
5
Destination Country
US
ENERGY STAR® Certified
true
Fuel Source
NATURAL
Installation Type
INDOOR
Application
RESIDENTIAL
Shipping Height
53.25
Shipping Length
31
Shipping Width
28.4
Side Loop
Yes
Voltage
120
Dimension & Venting
Type
Water Heater
Diameter
22"
Shipping Weight
216lbs
Vent Type
Power Vent
Product Literature
